Sears 1f56n-585 Mechanical Thermostat

Genuine Sears-branded mechanical (analog) thermostat for controlling single-stage heating and cooling systems. This is a simple, reliable, non-programmable thermostat that provides accurate temperature control without complicated electronics or digital displays.

✓ Simple Mechanical Operation - No programming needed, just set and forget
✓ Heat/Cool System Switching - Controls both heating and cooling
✓ Fan Auto/On Control - Manual fan control included
✓ Mercury-Free Design - Environmentally friendly snap-action contacts
✓ Universal Compatibility - Works with most 24V HVAC systems
✓ Durable Construction - Built to last for years
✓ Built-in Thermometer - Bimetal thermometer shows actual room temperature

Model Number: Sears 1F56N-585
Manufacturer: White-Rodgers / Emerson (OEM for Sears)
Type: Mechanical/Analog (Non-Programmable)
Condition: [Specify: New/Used/Refurbished]
Color: Beige/White
Mounting: Horizontal

Electrical Specifications:

• Voltage: 24V AC (30V AC Maximum)
• Voltage Type: Low Voltage
• Frequency: 50/60 Hz
• Current Rating (Heating): 0.15 to 1.2 Amps
• Current Rating (Cooling): 0 to 1.5 Amps
• Also Compatible With: Millivolt (750mV) systems

Control Specifications:

• Temperature Range: 50°F to 90°F (10°C to 32°C)
• Stages: Single Stage (1H/1C)
• System Switch: Heat - Off - Cool
• Fan Switch: Auto - On
• Humidity Range: 0-90% Non-condensing

Physical Specifications:

• Shape: Rectangular/Horizontal
• Wall Protrusion: Only extends 1-5/8" from wall
• Includes: Wallplate and mounting hardware

✓ Works With:

• Central Air Conditioners
• Central Gas Furnaces
• Central Oil Furnaces
• Central Electric Furnaces
• Heat Pumps (Single Stage, No Auxiliary Heat)
• Electric Heat Strips
• Space Heaters
• Hydronic (Hot Water) Heating Systems (3-wire zone valve)
• Millivolt Systems (gas fireplaces, wall heaters)

✗ NOT For Use With:

• Heat Pumps requiring auxiliary/emergency heat
• Multi-stage heating or cooling systems
• Line voltage systems (110V/240V baseboard heaters)
• Systems requiring programmable schedules

This Sears model is manufactured by White-Rodgers/Emerson

Equivalent/Similar Models:

• White-Rodgers 1F56N-444
• Emerson 1F56N-444
• White-Rodgers 1F56-444
• White-Rodgers 1F56W-444 (mercury version - discontinued)

Replaces Hundreds of Models: This thermostat was designed as a universal mercury-free replacement for hundreds of older White-Rodgers, Emerson, Honeywell, and competitive mechanical thermostats installed over the past 50+ years. Same footprint means no wall marks and no need for cover-up wallplate.

Standard Terminals:

• R or RH - 24V Power (Red wire)
• RC - Cooling Power (if separate transformer)
• W - Heat (White wire)
• Y - Cooling/Compressor (Yellow wire)
• G - Fan (Green wire)
• B or O - Heat Pump Reversing Valve (Orange/Blue wire)

Note: Factory jumper between RH and RC terminals for single transformer systems

• Sears 1F56N-585 Thermostat Body
• Mounting Subbase
• Wallplate
• Mounting Screws
• [Specify if instructions/manual are included]

[IMPORTANT: Add specific condition details here]

• Specify if new in box, used, removed from working system, etc.
• Note any cosmetic wear, scratches, discoloration
• Confirm all switches and temperature lever operate smoothly
• State whether it has been tested or guaranteed working

Difficulty Level: Easy (DIY-Friendly)
Estimated Time: 15-30 minutes
Tools Needed: Screwdriver only

SAFETY WARNING: ⚠️ TURN OFF POWER at circuit breaker before installation
⚠️ Do not use on circuits exceeding specified voltage
⚠️ If unsure about wiring, consult a licensed HVAC technician

Installation Tip: Take a photo of your existing thermostat wiring BEFORE disconnecting anything. This will make installation much easier!

Advantages Over Digital/Programmable:

• ✓ No batteries needed - Never worry about dead batteries
• ✓ Simple operation - Easy for anyone to understand
• ✓ Extremely reliable - Fewer electronic components to fail
• ✓ No programming required - Perfect for rentals, vacation homes, or people who prefer simplicity
• ✓ Lower cost - More affordable than digital models
• ✓ Proven technology - Mechanical thermostats have been used reliably for 50+ years

Perfect For:

• Rental properties
• Vacation homes/cabins
• Senior citizens who want simplicity
• People who maintain constant temperature
• Basements, garages, workshops
• Replacement for failed digital thermostats

• Single-family homes
• Apartments and condos
• Mobile homes
• Commercial spaces with simple HVAC needs
• Rental properties
• Small businesses
• Churches and community buildings
• Warehouses and workshops

Brand Heritage: Sears/Kenmore thermostats were manufactured by White-Rodgers, a division of Emerson Electric. White-Rodgers has been producing quality HVAC controls since 1906 and is one of the most trusted names in the industry.

This is an older-style mechanical thermostat from when Sears was a major appliance retailer. While functional and reliable, it also represents a piece of American home comfort history. Perfect for those maintaining period-correct homes or who prefer vintage mechanical controls.

Q: Will this work with my heat pump?
A: Yes, but ONLY for single-stage heat pumps WITHOUT auxiliary/emergency heat. If your system requires E or AUX heat terminals, you need a different thermostat.

Q: Can I use this with my programmable schedule?
A: No, this is a non-programmable thermostat. You manually adjust the temperature as needed.

Q: What if I have a 2-stage furnace or AC?
A: This thermostat is for single-stage systems only. Multi-stage systems require a different model.

Q: Will this fit where my old thermostat was mounted?
A: Very likely yes! White-Rodgers mechanical thermostats have used the same footprint for decades, so wall marks usually aren't a problem.

Q: Does it work with baseboard heaters?
A: No, baseboard heaters typically use line voltage (110V-240V). This thermostat is for low voltage (24V) systems only.

[Customize this section based on your shipping policies]

📦 Careful Packaging - Thermostats are fragile and will be packed securely
📦 Fast Shipping - Ships within [specify timeframe]
📦 Tracking Provided - Track your package every step of the way

⚠️ Wiring Verification: Please verify your existing thermostat is 24V low voltage before ordering. If you have baseboard heaters, wall-mounted line voltage thermostats, or are unsure, this may not be the correct thermostat for your system.

⚠️ Mercury Thermostats: If you are replacing an old mercury thermostat, please dispose of it properly at a household hazardous waste facility. Visit [link removed by eBay] for proper disposal information.

⚠️ Professional Installation: While this is a straightforward DIY installation for most homeowners, electrical work should only be performed by qualified individuals. When in doubt, hire a licensed HVAC technician.
